Silicon Deep RIE System RIE-800iPB


Samco's RIE-800iPB is a high performance inductively coupled plasma (ICP) etching system that uses high-density plasma to perform deep silicon etching required by MEMS and TSV applications.
The RIE-800iPB is a dedicated silicon etching system specifically designed for the Bosch process (licensed from Robert Bosch GmbH). The systems' unique reaction chamber, electrode, stage and vacuum design overcomes the problems encountered in competing systems to allow High Rate (~50 μm/min), Tilt Free, High Aspect Etching with industry leading selectivity (over 100:1).

Key Features and Benefits

  • High rate etching in MEMS mass production
  • High aspect ratio etching in mass production
  • Control of scalloping / Scallop-less non-bosch process
  • Excellent uniformity with tilt control
  • Bias pulsing for notch control at silicon on insulator (SOI) wafers
  • Extended process library


  • MEMS (acceleration sensors, gyroscopes, pressure sensors, actuators, etc.)
  • Through Silicon Via (TSV)
  • Processing of the inkjet printer head
  • Power devices (super-junction MOSFETs)
  • Plasma Dicing/Scribing
